Cold Storage Size 12.2 m x 2.4 m x 2.6 m (40 Feet Container)
Included:
40 feet container
Wall/Ceiling: 100mm thick PIR Panel with slip joint
Floor: 100 mm thick Floor panels with 12 mm WBP plywood and finished with non-slip chequered aluminum sheet
Single Leaf Hinged Door - 01 no.
Flashings
24K BTU VacKool cooling unit - 01 no. & 18K BTU VacKool cooling unit - 02 nos. to maintain temperature 3°C to 5°C
Solar Panels and 4 nos. of 3kW ESS Packages

Specifications of 3kW ESS Package:
Solar input (3kW), Battery, and AC in/out either by off-grid or grid-tied.
12.5kWh Li-ion Battery
Two cabinet (Main+Batt-Ext)
Battery Voltage 250Vdc
AC single phase 220Vac 50/60Hz

(Solar power generation subject to peak sunlight hours. Above consideration was done assuming average of 5.8 peak sunlight hours. For first time use please charge the battery bank completely before use.)
