iMini Plus PDF logger MU-OE-D-16-L

185.82 USD 185.82 USD 185.82 USD

650.00 AED

iMini Plus PDF logger MU-OE-D-16-L

iMini PDF Data logger MU-OE-D-16-L
With 1-meter temperature external probe
16K memory option
-40° to + 70°C temperature range

VSKU: 1000000019

185.82 USD 185.82 USD 185.82 USD

650.00 AED

This combination does not exist.

Add to Cart Buy Now

Category:

Temperature Data Logger

Description
Ratings and Reviews

16000 readings Plug & Play Multi use Temperature data logger with external sensor

Reusable Temperature data logger with memory capacity of 16000 readings (Plug & Play device) with an external sensor probe. This does not require any special software for generating the reports. Pdf reports are automatically generated.

This is our reusable external sensor temperature data logger with plug and play feature. It can generate pdf report without installing any special software. The data download is through a USB cable which can be connected on the back side of the data logger. It has a memory capacity of 16000 readings which means it can record for 54 days if sampling rate is kept as 5 minutes.

It has a steel external sensor with a sensor cable approximately one meter long. Simply connect the data logger to a PC using the USB cable and pdf report is automatically generated. The user can reuse this temperature data logger any number of times after downloading the data. The user can see the current readings on the screen of the logger. After downloading the data simply press the start button to start recording once again.

Features

It does not require any special software for downloading the data.
You can restart the data logger after downloading the data without any reprogramming.
User can easily replace the coin type battery without our assistance.
It is connected using a USB cable and hence does not require any dock or adaptor to connect to the computer.

Specifications

PRODUCT CODE VD-DL-TMP-CP-00111
MODEL MU-OE-D-16-L
MEASUREMENT PARAMETERS Temperature
UNIT OF MEASUREMENT °C or °F
MEMORY CAPACITY 16K; 16240 readings
DURATION OF RECORDING 360 days
MEMORY TYPE Electronic
PROGRAM INTERVAL 5 seconds to 18 hours
SENSORS External sensor
MEASURING RANGE (PARAMETER 1) -40 °C to +70 °C (-40 °F to +158 °F)
ACCURACY (PARAMETER 1) ±0.5 °C (-40 °C to -10 °C), ±1 °F (-40 °F to +14 °F) ±0.3 °C (-10 °C to +70 °C), ±0.6 °F (+14 °F to +158 °F)
RESOLUTION 0.1 °C (0.1 °F)
SENSOR RESPONSE TIME External Sensor – T90 of 5 minutes in moving air
DISPLAY Yes
SPECIAL SOFTWARE REQUIRED FOR DATA DOWNLOAD? No
REMOTE MONITORING No
LCD OPERATING RANGE -20 °C to +70 °C (-4 °F to +158 °F)
ALARM THRESHOLDS Two
ALARM CONFIGURATION High & low
ALARM TYPE On screen
BOOKMARK Yes
PREPROGRAM OPTION User programmable Preprograming available
START OPTION Push button and/or timer
AUTO START Yes; on multi-use loggers
START DELAY Yes
STOP OPTION Yes, Stop button (can be disabled)
DIMENSION 83 x 57 x 17mm (excluding lug)
WEIGHT (KG) 0.0700
CASE MATERIAL Polycarbonate/ABS
POWER 3.0V, user replaceable
IP RATING IP65 (with plastic cap over USB connector)
WARRANTY 24 months, excluding battery
CALIBRATION Upon request at extra charge
TEST CERTIFICATE Yes
OTHER CERTIFICATION ISO9001:2008, CE, RoHS, EN12830
BATTERY LIFE 1-2 years (depending on usage)
COMMUNICATION USB (included)
SOFTWARE Console Pro (Free)
DEFAULT FILE FORMAT PDF & LRF
DATA EXPORT TXT, CSV, SYLK & LCF
SECURITY Password protected (programmable using Console Pro Software) encrypted binary file is generated along with PDF
PLUG & PLAY DOWNLOAD OF DATA Yes
PACKAGE INCLUDES Data logger & USB cable
DETAILED MANUAL Read Manual / Download Manual
VIDEO LINK Watch Product Video
MANUFACTURER Cryopak, USA
