Real Time Monitoring HWg-Ares 12 Plain

1,000.55 USD 1,000.55 USD 1000.5500000000001 USD

3,500.00 AED

Real Time Monitoring HWg-Ares 12 Plain

Ares 12/14 GSM Thermometer with email (GPRS) and SMS Alerts
Sensors: 2xRJ11 for 1-Wire UNI
M2M communication protocols: SNMP, XML, Box-2-Box
GSM/GPRS: Quad-Band 850/900 / 1800/1900 MHz - SMA antenna connector
WEB: Built-in web server
Online portal: SensDesk.com(Free online portal)
Mechanical: 76 x 93 x 28 mm, wall-mountable, fits on a DIN rail

Days
Hours
Mins
Secs
1

VSKU: 1005000033

1,000.55 USD 1,000.55 USD 1000.5500000000001 USD

3,500.00 AED

    This combination does not exist.


    Add to Cart Buy Now


    Ares 12/14 GSM Thermometer with Email (GPRS) and SMS Alerts

    Ares 12 is a device or an industrial unit for remote monitoring and alarming over GSM for locations without LAN access. Ares 12 includes battery backup. Ares 12 can connect up to 14 external sensors and 2 dry contact detectors.
    Ares 12 product also support FOTA i.e. Firmware over the Air for firmware updates.

    Features
    It is connected with GSM/GPRs quad band 850/900/ 1800/1900 MHz- SMA antenna connector.

    Its configuration consists of over USB, configuration utility on a Mass storage drive. No need to install.

    FW upgrade consist of over USB, or FOTA(Firmware Over The Air)over GPRS.

    The device power is 9-30 VDC/0.5 A external power. Their internal battery powers consist of: Powers the device +sensors for 3-8 hours. It depends on sensors. Battery life is 5 to 12 years depending on the type usage and operating temperature.

    This device consist of flash log i.e. 2Mb170, 000 records, for example 3 sensors @5 minutes – 200 days.

    It consists of 2 digital inputs for dry contact status detectors pulse counter.

    It consist of 2x RJ11 for 1-Wire UNI sensor.

    HWg-Ares12 supports 3 sensors.

    HWg-Ares14 supports 14 sensors.

    It also diagnoses external power detection and battery status.

    It also send alarm alerts through email, HWg Push , SMS

    It’s authentication is done by google SMTP

    HWg SDK is supported for the programmers.

    There is a facility of mobile application for data review. It has both android and iphone device via SensDesk.com.

    It could be configured remotely through the web interface via SensDesk.com free online portal.

    It is supported by software such as:

    HWg-PDMS

    HWg-Push Nagios plugin

    SensDesk.com which is free online portal.

    Usage
    GPRS monitoring of a server room without connecting to the local LAN

    Diesel generators – environment and status monitoring

    Back-up power supply systems

    ATM (Automatic Teller Machines) environment monitoring

    Cooling systems and coolers

    Antennas and microwave links

    Technology along roads, highways, or railroad tracks

    Temperature and displacement of structures

    Storages of food or materials

    Art exhibits and depositories

    Agricultural production premises (greenhouses, granaries, etc.)

    Electricity distribution networks (transformer stations, lines)

    Water source monitoring, including technical equipment status

    Monitoring of appliances with consumable, refillable content (vending machines for coffee, sandwiches or drinks, massage chairs, ...)

    We supply this Ares 12 VAC- ares which  is an industrial unit for remote monitoring and alarming over GSM for locations without LAN access  in the USA, UK, Germany, France, Netherlands, Spain, Switzerland, Sweden and other European countries. Also, we supply Ares 12 VAC- ares which is an industrial unit for remote monitoring and alarming over GSM for locations without LAN access in the Middle East and other Asian countries including India, Pakistan, Afghanistan, Bangladesh, Singapore, etc. Our African offices supply these Ares 12 VAC- ares which is an industrial unit for remote monitoring and alarming over GSM for locations without LAN access in across all African countries covering South Africa, Kenya, Nigeria, Tanzania, Rwanda, Djibouti, Morocco, Ghana, Ethiopia, Uganda, Morocco, Tunisia, Cameroon, Mauritius, Gabon, Seychelles, etc.

    Our Middle East offices supply these Ares 12 VAC- ares which is an industrial unit for remote monitoring and alarming over GSM for locations without LAN access in in the United Arab Emirates, Kingdom of Saudi Arabia, Qatar, Oman, Kuwait, Egypt, Lebanon, Bahrain,  Libya, Iraq, Erbil, Jordan, etc.
