B1500 Turbine Flow Meter

B1500 Turbine Flow Meter

B1500 Turbine Flow Meter model no [VAC- B1500- Turbine- Flow- Meter]

Size 1/4 to 2 in.
Temperature Range -150 to 300 °F
Flow Range 0.25 to 250 gpm
Pressure Range Up to 5922 PSI
Accuracy (with B3000 linearization) ± 0.25 %
(with K-factor only) ± 0.5 %



    This combination does not exist.

    Contact Us


    B1500 Turbine Flow Meter consists of a cylindrically bored housing, a flow straightener and turbine assembly, and a magnetic pickup. The magnetic pickup is located directly above the turbine, near the downstream end of the flow meter. The flow straightener and turbine assembly are retained in the housing by a snap. The Blancett B1500 flow meter is designed to provide a high-frequency output voltage at the maximum of their flow range. It is made with wear-resistant moving parts for good operation and for long service life. These equipment are easy to repair. Higher calibrations can be achieved for a specific viscosity. The Fluid which passes through the meter causes the rotor and bearing to revolve at a speed directly proportional to fluid velocity. When each rotor blade passes the pickup, it varies the pickup’s reluctance, producing an output signal. As turbine speed is directly proportional to fluid velocity, signal frequency is similarly proportional to the volumetric rate-of-flow. The output signal can be fed into various types of instruments, such as indicators, frequency converters, counters, recorders, and controllers to show the rate-of-flow.

     Applications of B1500 Turbine Flow Meter model no [VAC- B1500 –Turbine- Flow- Meter]

    1. It can be used in petrochemical industries.

    2. It can be used in refining industries.

    3. It can be used in chemical metering.

     Features of B1500 Turbine Flow Meter model no [VAC- B1500 –Turbine- Flow- Meter]

    1. It has expanded mechanical linearity

    2. It is made by helical rotor design

    3. It has high-performance ceramic ball bearings

    4. It supports a 6-bladed rotor

    5. It supports NIST traceable standard

    Specifications of  B1500 Turbine Flow Meter model no [VAC- B1500 –Turbine- Flow- Meter]

    • Its size can range from ¼ to 2 in.

    •  Its working temperature range is -15o to 300 °F.

    • The flow range is 0.25 to 250 GPM.

    • The pressure range is Up to5922 PSI.

    • The accuracy is ±0.25 % with B3000 linearization and ± 0.5 % with k-factor only.

    We supply a B1500 Turbine Flow Meter that can be used in various industries and applications in the United Arab Emirates. Contact us for this B1500 Turbine Flow Meter in Dubai, Abu Dhabi, Sharjah, RAK, UAQ, Ajman &  Fujairah too.
