Continuous level sensor (guided wave radar)

571.74 USD 571.74 USD 571.74 USD

2,000.00 AED

Continuous level sensor (guided wave radar)

Product characteristics
Number of inputs and outputs Number of digital outputs: 1; Number of analog outputs: 1
Probe length L [mm]: 100...1600
Process connection: G 3/4 external thread
Electrical data
Operating voltage [V] 18...30 DC
Current consumption [mA] < 80
Protection class III
Reverse polarity protection yes
Power-on delay time [s] < 3
Inputs / outputs
Number of inputs and outputs Number of digital outputs: 1; Number of analog outputs: 1
Outputs
Total number of outputs 2
Output signal switching signal; analog signal; IO-Link
Electrical design PNP
Number of digital outputs 1
Output function normally open / closed; (configurable)
Max. voltage drop switching output DC [V] 2.5
Permanent current rating of switching output DC [mA] 200
Number of analog outputs 1
Analog current output [mA] 4...20
Max. load [Ω] 500
Analog voltage output [V] 0...10
Min. load resistance [Ω] 2000
Short-circuit protection yes
Type of short-circuit protection thermal, pulsed
Overload protection yes
Measuring/setting range
Probe length L [mm] 100...1600
Active range A [mm] L-40 (L-60); (when set to oil and oil based media)
Inactive range I1 / I2 [mm] 30 / 10 (30); (when set to oil and oil based media)

Days
Hours
Mins
Secs
1

VSKU: VAC-LR3000

571.74 USD 571.74 USD 571.74 USD

2,000.00 AED

    This combination does not exist.


    Add to Cart
