A cutting-edge transmitter with an installer- and user-friendly design is the Advance Sensor with Air Change (ACPH) 6283. Many of the issues that plague conventional sensors are resolved by the 6283, which also offers the greatest amount of flexibility. Field-selectable characteristics on the device include Unit (Pascal, l/s m/s ACPH), Signal output (mA or Volt), and Signal volt outputs (0- 10, 0-5, 2-10). Depending on the models chosen, a variety of predefined measuring ranges (5, 10) are available. The user can alter these ranges to alternative values. For instance, if you choose the 50 range and would like to convert it to a 0-60 range.

You can cover the majority of conditions for measuring room pressure, HVAC duct flow, and other things with all these settings in one sensor. Choose unit l/s or ACPH if the airflow is in a duct. Duct size and k-factor should be set for l/s. Simply adjust room loudness for ACPH. The output is set up to operate in Uni or Bidirectional mode if the room pressure application and 6283 [B] Bidirectional version are both present. The 6283 also features a display and push buttons to make the settings simple during installation.

    Features:

• LED-Display for setup

• Field selectable output

• Field selectable unit

• Optional Alarm relay

• Accurate/Flexible

• ACPH, l/s, m/s, Pa

• ModBus

• Optional Auto calibration

• Easy to install and configure

• Optional visible display

• Volt and mA output

• CPS ready

    Specifications:

• Range*

6283_500 - 0-500 Pa

6283_B_250 - ± 250 Pa

6283_B_500 - ± 500 Pa

6283_B_1250 - ± 1250 Pa

6283_2500 - 0-2500 Pa

*Other ranges available on request

• Nonlinearity - ± 0,3 pascal +0,1% of reading, typical

• Stability - ± 0,2 % typ.(1 year) Typical

• The time constant - 0.1 - 20 seconds

• Output - 0-5, 1-5, 0-10, 1-10, 2-10 V or 4-20mA, 0-20 mA

• Output Range - Unit depending, select in steps

• Resolution - 10-bit digital output

• Supply - 18-24 V AC/DC, 50 mA

• Optional Relay - 24 VAC/DC 1A max

• Humidity range - 0...95 % RH (non-condensing)

• Dimension - 125x90x60 mm

• Weight - 530 g

• Hose connectors ø - 5/ 6/ ¼” mm specified at order
