High Speed 8 Channel Multifunction Data Logger

High Speed 8 Channel Multifunction Data Logger

This model has 8 channels for measuring for voltage, temperature, humidity, pulse and logic inputs. It has a 5.7 inch LCD colour display.



    This combination does not exist.

    Contact Us


  • Data Logger

  • 8 channel multi function, high speed data logger with display

    This 8 channel data logger can directly transfer the recorded data into an Microsoft Excel format.It has a built in large 5.7 inch colour display screen which can show wave forms.


    1. It has high speed simultaneous sampling on 8 channel, 16 bit resolution.

    2. The user can easily transfer the data to USB memory drives.

    3. Also, remote monitoring is possible through Ethernet and ftp. It can take inputs from any type of Thermocouples.


    1. Product Code VD-DL-MUL-GR-04202

    2. Model GL 900

    3. Free Shipping No

    4. Measurement Parameters Voltage, Temperature, Humidity, Pulse, Logic

    5. Unit Of Measurement No

    6. Memory Capacity 256 Mb Capable Of Storing One Million Data Points

    7. Duration Of Recording 365 Days Based On Sampling Interval

    8. Memory Type Internal Flash Memory

    9. Program Interval 10μs To 1 Min

    10. Sensors  External Upto 8 Channels

    11. Measuring Range (Parameter 1)  20, 50, 100, 200, 500 Mv; 1, 2, 5, 10, 20, 50, 100, 200, 500 V F.S., 1-5 V F.S.

    12. Measuring Range (Parameter 2)  Type: K, J, E, T, R, S, B, N, W (Wre5-26) Range: 100, 500, 2000 ºc

    13. Measuring Range (Parameter 3)  Humidity:0 To 100% RH- Using The Humidity Sensor (Option B-530)

    14. Measuring Range (Parameter 4)  RPM Mode, Countr Mode & Inst Mode

    15. Measuring Range (Parameter 5)  Logic Input (4 Channels) Or Pulse Input (4 Channels)

    16. Accuracy (Parameter 1)  Please See The Detailed Specification

    17. Accuracy (Parameter 2)  Please See The Detailed Specification

    18. Accuracy (Parameter 3)  Please See The Detailed Specification

    19. Accuracy (Parameter 4)  Please See The Detailed Specification

    20. Accuracy (Parameter 5)  Please See The Detailed Specification

    21. Resolution Please See The Detailed Specification

    22. Sensor Response Time NA

    23. Display Yes

    24. Special Software Required For Data Download? Free Software

    25. Remote Monitoring Yes

    26. Lcd Operating Range Please See The Detailed Specification

    27. Alarm Thresholds Programmable

    28. Alarm Configuration Programmable

    29. Alarm Type External Alarm Outputs

    30. Bookmark NA

    31. Preprogram Option User Programmable

    32. Start Option Autostart / User Programmable

    33. Auto Start Yes

    34. Start Delay NA

    35. Stop Option NA

    36. Dimension 232 X 150 X 80 MM (W X H X D)

    37. Weight (Kg) 1.1000

    38. Case Material Polycarbonate/ABS

    39. Power Ac Adaptor, 8.5 To 24 V Dc, Optional Mountable Battery Pack

    40. Ip Rating NA

    41. Warranty 12 Months, Excluding Battery

    42. Calibration Upon Request At Extra Charge

    43. Test Certificate Yes

    44. Other Certification NA

    45. Battery Life Based On Usage And Number Of Sensors Connected.

    46. Communication  USB Or Ethernet

    47. Software Http://Www.Graphteccorp.Com/Support/Software/Instrument/Gl900aps(E)V206.Zip

    48. Default File Format GBD,CSV format

    49. Data Export GBD,CSV format

    50. Security      NA

    51. Plug & Play Download Of Data Free Gl-connect Software Required

    52. Package Includes Data Logger, Ac Adaptor

    53. Detailed Manual Read Manual / Download Manual

    54. Video Link NA

    55. Manufacturer Graphtec, Japan

    56. Price AED12,085.00
