DFRD-045-E Desiccant Dehumidifier (50Hz)

5,115.63 USD 5,115.63 USD 5115.63 USD

17,895.00 AED

DFRD-045-E Desiccant Dehumidifier (50Hz)

DFRD-045-E Desiccant Dehumidifier

Process/Dry Air Flow: 350 Nm3/h
Available Pressure for Ducting: 400 Pa
Reactivation Air Flow:100 Nm3/h
Available Pressure for Ducting: 100 Pa
Nominal Drying Capacity (*): 1,7 kg/h
Total Power Supply: 3 Kw
Electrical Supply: 230V/I+N/50Hz

Days
Hours
Mins
Secs
1

VSKU: 1001000369

5,115.63 USD 5,115.63 USD 5115.63 USD

17,895.00 AED

    This combination does not exist.


    Add to Cart Buy Now


                                                            DFRD-045-E Desiccant Dehumidifier


    The DFRD-045-E desiccant dehumidifiers are an ideal choice for challenging air-drying conditions. They come with dual fans, as it is not feasible to blend the process air with the surrounding high-humidity or damp air under these conditions. Consequently, these separates fans effectively segregate the process and reactivation airflows.

    These compact DFRD-045-E desiccant air dehumidifiers boast a stainless-steel design and are prepared for immediate use. Furthermore, they are engineered to achieve remarkably low dew points, rendering them especially well-suited for deployment and application in specific industries.


    Features

    1. Self-supporting stainless-steel furniture with a handle

    2. Air drawn in through G3 filters via two single-ear centrifugal fans and direct motors (one for dry air, one for wet air)

    3. Desiccant rotor rotates with a reducer motor and toothed belt

    4. Friction sector and perimeter closure joints

    5. Material reactivated with a self-limiting PTC heater

    Applications

    1. Plastic forming industry

    2. Seed conservation

    3. Libraries

    4. Archives

    5. Museums

    Specifications

    1. Process/Dry air flow   350 Nm3/h

    2. Available pressure for ducting   400 Pa

    3. Reactivation air flow   100 Nm3/h

    4. Available pressure for ducting   100 Pa

    5. Nominal drying capacity (*)   17 Kg/h

    6. Total power supply   3 Kw

    7. Motors poser   0,5 Kw

    8. Reactivation heater power   2,5 (nominal) and 3,1(maxim) Kw

    9. Electrical supply   230 V/I+N/50Hz
