Flameproof Solvent Vapors Detector-Transmitter E2658-PID-200

1,807.27 USD 1,807.27 USD 1807.27 USD

6,322.00 AED

Flameproof Solvent Vapors Detector-Transmitter E2658-PID-200

Flameproof Solvent Vapors Detector-Transmitter E2658-PID
Detected vapors: Acetone, Benzene, Ethanol, Ethyl Acetate, Toluene, Xylenes
other VOC with ionisation potential < 10.6 eV
Default calibration: Isobutylene
Sensor type: Photoionisation detector (PID)
Sampling method: Diffusion
Detection range: 0...40 ppm or 0...200 ppm
Resolution: 1 ppb/< 50 ppb
Sensor lifetime: up to 5 years
Power supply: 11...30 VDC, 24 VAС, or 230 VAC
Digital interface: RS485, Modbus RTU protocol
Analog outputs: 2 × 4-20 mA / 0-10 V, user settable
Output relays (option) 2 × SPST relays (closing contact),
250 VAC / 30 VDC, 5 A max
Enclosure: Grey die-cast aluminium, wall mount
Protection class: IP66

VSKU: 1014000008

1,807.27 USD 1,807.27 USD 1807.27 USD

6,322.00 AED

This combination does not exist.

Add to Cart Buy Now

Category:

Gas Detector

Description
Ratings and Reviews

Flameproof solvent vapors transmitter for ATEX Zones 2 & 22

Flameproof Solvent Vapors Detector-Transmitter is designed to detect compounds with ionizing potential < 10.6 eV. It is manufactured by Evikon MCI Ltd, Estonia, specializing in gas detection systems. The system uses extremely sensitive photoionization detectors (PIDs) with remarkably low minimum detection rates. The system is designed for safe zone operation and ATEX Zones 2 and 22.

This flameproof solvent vapors detector-transmitter can be controlled by Modbus RTU commands via its RS485 interface. The RS485 Modbus RTU digital communication interface enables fast configuration of the instrument and incorporation into different automation systems. It also features 2 independent analog outputs. Users can configure it to 4-20 mA or 0-10 V, proportional to the concentration of either gas or temperature.

It has a robust flameproof metal enclosure and is wall-mounted. It has relay outputs available. Two RE1 and RE2 relays with closing contacts can be used to turn alarm sirens, ventilators, shut-off valves or other actuators operated at 24 V or 230 V. The device can be calibrated monthly or more frequently depending on the operating conditions.

Applications

It is used to detect hazardous solvent vapors in painting chambers and booths.
It is used in solvent leak detection areas and warehouses for the storage of solvents.
It is used for tracking employee exposure to solvent vapors in the printing press.
It is commonly used in oil & gas, refining, petrochemicals.
It is commonly used in factories using solvents and environmentally harmful applications.
It is used primarily during the cleaning and degreasing phase in the production of textiles.
It is used in the solvent processing and filling sectors.

Features

It is suitable for ATEX Zones 2 and 22.
A relay option is available.
Ranges of measurement of this flameproof solvent vapors detector-transmitter are 0-40 ppm or 0-200 ppm.
Resolutions of measurement of VAC-E2658-PID are 1 ppb or 1 ppm.
Users can configure the 2 analog outputs to 4-20 mA or 0-10 V.
It features RS485 Modbus RTU protocol for fast connectivity to BMS systems.
The transmitter demonstrates sensitivity to substances with ionizing potential below 10.6 eV, which is to the majority of solvent vapors.

Specifications

The response time T90 of this flameproof solvent vapors detector-transmitter for use in solvent storage areas and warehouses is < 3 seconds.
The sensor lifetime of this flameproof solvent vapors detector-transmitter, model no. VAC-E2658-PID is 5 years.
It can be calibrated monthly or more frequently depending on the operating conditions.
The signal update is every 1 second.
The self-diagnostics function of this flameproof solvent vapors detector-transmitter for use in ATEX Zones 2 and 22 performs a full functionality check at start-up.
It has a warm-up time of ≤ 1 min.
It can detect vapors such as Acetone, Benzene, Ethanol, Ethyl Acetate, Toluene, Xylenes and other VOC with ionization potential < 10.6 eV.
The default calibration of this flameproof solvent vapors detector-transmitter for use in painting chambers and booths is Isobutylene.
The sensor type used is a Photoionization Detector (PID).
The sampling method of this flameproof solvent vapors detector-transmitter is diffusion.
The typical detection ranges are 0-40 ppm or 0-200 ppm.
The resolution for VAC-E2658-PID-40 is 1 ppb while VAC-E2658-PID-40 is 1 ppm.
The power supply of this flameproof solvent vapors detector-transmitter, model no. VAC-E2658-PID is 11-30 VDC / 24 VAC. The power unit of 90-265 VAC is available on request.
It has < 2 VA power consumption.
It has an RS485 digital interface with Modbus RTU protocol.
It has 2 analog outputs settable at 4-20 mA / 0-10 V.
It can be operated in industrial indoor and outdoor areas, safe areas, and ATEX Zones 2 and 22.
The operating conditions of this flameproof solvent vapors detector-transmitter, model no. VAC-E2658-PID are -40 to+55 °C at <95 %RH (best stability in the range 0 to 40°C) with 0.9-1.1 atmospheric pressure.
It has a grey die-cast aluminum enclosure and an IP66 safety rating.
The dimensions of this flameproof solvent vapors detector-transmitter, model no. VAC-E2658-PID are H120 × W125 × D57 mm.
It has flameproof protection, ATEX: II 2 GD, Ex ed IIC T4 Gb.
The cable gland is M25 for SWA cable or steel conduit Ø10-17 mm.
It has 0.5-1.5 mm2 wire conductors.

Relay option (ordering code R)

It has 2 SPST output relays (closing contact) with 250 VAC / 30 VDC at 5 A max current.
The default alarm set-points are defined by the user.

We supply these Flameproof Solvent Vapors Detector-Transmitters in all Middle East countries including the United Arab Emirates, Kingdom of Saudi Arabia, Oman, Qatar, Bahrain, Iraq, Lebanon, Egypt, Jordan, Libya, Tunisia, etc.
